Shaft awnings are window awnings designed for installation in existing on-site shafts or lintel boxes. The system uses the available cavity instead of a separate awning box. When retracted, the fabric and drive components are largely concealed. Suitability depends on shaft dimensions, fixing points, maintenance access, drainage and the selected guidance system.
WAREMA shaft awnings are exterior fabric shading systems designed for installation in a building-side shaft or lintel box.
Depending on the product, the fabric may be guided by cables, rails, easyZIP guidance, a drop arm or a markisolette projection system. The shaft must provide sufficient installation space, secure fixing points, drainage and maintenance access.
Availability varies by country.
- maximum order width 3000 mm
- maximum order height 3000 mm
- Maximum order area 9 m²
- Slender cable guidance
- Without box
- Fixation via consoles
- maximum order width 3500 mm
- maximum order height 4000 mm
- Maximum order area 12 m²
- Rail-guided external venetian blinds
- Without box
- Fixation via consoles
- maximum order width 4000 mm
- maximum order height 1600 mm
- Maximum order area 6.4 m²
- Drop arm
- Without box
- Optional clamping supports
- maximum order width 4000 mm
- maximum order height 3500 mm
- Maximum order area 14 m²
- Projection system
- Without box
- Attachment via guide rail
- maximum order width 4000 mm
- maximum order height 4000 mm
- Maximum order area 12 m²
- Rail-guided external venetian blinds
- Without box
- Attachment via guide rail
- maximum order width 4000 mm
- maximum order height 4500 mm
- Maximum order area 18 m²
- Wind-stable easyZIP guidance
- Without box
- Attachment via guide rail
Shaft awnings are used where exterior window shading should remain largely concealed when retracted. Depending on the selected model, guidance and awning fabric, they can reduce incident sunlight and glare and provide different levels of outward view and visual privacy. A markisolette projects the lower fabric section away from the façade, which can retain more daylight and outward view.
- Integration into a suitable on-site shaft or lintel box
- Cable, rail, easyZIP, drop-arm or markisolette variants, depending on the model
- No separate external box for compatible shaft details
For shaft awnings, fabric and aluminium finishes are selected according to the desired façade appearance and interior light conditions. Fabric colour, openness and material influence daylight, outward view, glare control and visual privacy. Available choices depend on the product and country.
- Façade appearance: coordinate fabric and aluminium finishes
- Daylight and outward view: compare the awning fabric for the selected product
- Care: follow product- and fabric-specific cleaning instructions
When retracted, the fabric shaft and much of the mechanism are housed within the on-site shaft. Guide rails, end rails or other components may remain visible, depending on the product and installation detail.
Shaft awnings are primarily designed to reduce solar radiation and glare. The level of light reduction depends on fabric colour, openness, guidance, dimensions and installation details. They should not be described as blackout systems unless the selected product and configuration are specified for that purpose.
Permitted wind loads depend on the model, guidance system, dimensions, fabric, fixing and installation location. The product-specific wind limits and operating instructions apply. More stable lateral guidance may be required for exposed locations or larger dimensions.
A shaft awning can be considered for renovation when a suitable existing shaft or lintel box is available, or when one is created as part of the building work. Available space, fixing conditions, drainage and service access must be checked before selection.
The following details should be coordinated before selecting a shaft awning:
- Maintenance access: keep inspection, adjustment and service points accessible.
- Shaft dimensions: allow space for the fabric shaft, drive, guidance and end rail.
- Fixing and interfaces: verify the substrate, fixing points, window sill and reveal geometry.
- Drainage and soiling: detail the shaft so that water can drain and debris does not accumulate.
- Wind and operation: select the model, guidance and controls for the installation location and product limits.
View product examples at a Sunlight Experience Centres or contact a WAREMA specialist retailer. The retailer can assess the window dimensions, façade construction, fixing points, fabric, guide system, controls and installation requirements before preparing a quotation.
